Talbert Manufacturing
30-55 FG
- Capacity
- 30 ton
Specifications
Capacity
- Capacity: 30-55 Ton
- RIDEWELL Suspension: Air Ride with Manual Raising And Lowering Hand Valve
- Full Capacity Evenly Distributed
- Axles: 25,000 lb. Capacity lbs
- Full Capacity Less 10,000 lbs. in 10 in. 0 ft.
- Brakes: 16-1/2 in. x 7 in. with Automatic Slack Adjusters
Dimensions
- Deck Height: 18 in. Loaded
- Wheels: Steel Disc, Hub Piloted, Outboard Mounted Drums
- Road Clearance: 6 in. Loaded
- Lights: 12 Volt DOT LED Rubber Mounted with Sealed Harness
- Full Width Rear Bridge Platform with 1-1/8 in. Shiplap Apitong and 4 Lashing Slots Each Side
- Valspar R-Cure 800 Red or Black Paint
Construction
- 1-1/2 in. Apitong Flooring Outside Mainbeams
- Options: 3rd Axle (Removable or Fixed)
General
- Cross Members on 24 in. Centers
- Estimated Empty Weight: Starting at 14,920 lbs.
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
