Talbert Manufacturing
30-55 HRG
- Capacity
- 30 ton
- Deck height
- 16 in
Specifications
Capacity
- Capacity: 30-55 Ton
- Tapered Bridge Ramp with Traction Bars (HRG/SRG)
- Full Capacity Evenly Distributed
- Full Width Rear Bridge Platform with 1-1/8 in. Shiplap Apitong and 4 Lashing Slots Each Side tons
- Full Capacity Less 10,000 lbs. in 10 in. 0 ft.
- RIDEWELL Suspension: Air Ride with Manual Raising And Lowering Hand Valve
Dimensions
- Deck Height: 18 in. Loaded
- Brakes: 16-1/2 in. x 7 in. with Automatic Slack Adjusters in
- Road Clearance: 6 in. Loaded
- Tires: 255/70R22.5 (H) 16PR
- 10 Lash Rings (5 Each Side of Deck) (HRG/SRG
- Estimated Empty Weight: Starting at 14,920 lbs.
Construction
- Four-Beam Design (HRG/SRG)
- Wheels: Steel Disc, Hub Piloted, Outboard Mounted Drums
- 1-1/2 in. Apitong Flooring Outside Mainbeams
- Lights: 12 Volt DOT LED Rubber Mounted with Sealed Harness
General
- 12 in. Outriggers (HRG/SRG)
- Options: 3rd Axle (Removable or Fixed)
- Cross Members on 24 in. Centers
- Valspar R-Cure 800 Red or Black Paint
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
