Talbert Manufacturing
30-55 SRG
- Capacity
- 30 ton
- Deck height
- 255 in
Specifications
Capacity
- Capacity: 30-55 Ton
- Tapered Bridge Ramp with Traction Bars (HRG/SRG)
- Full Capacity Evenly Distributed
- Full Width Rear Bridge Platform with 1-1/8 in. Shiplap Apitong and 4 Lashing Slots Each Side tons
- Full Capacity Less 10,000 lbs. in 10 in. 0 ft.
- RIDEWELL Suspension: Air Ride with Manual Raising And Lowering Hand Valve
Gooseneck
- Rollers at Front of Gooseneck (SRG)
- Axles: 25,000 lb. Capacity
Dimensions
- Deck Height: 18 in. Loaded
- Tires: 255/70R22.5 (H) 16PR
- Road Clearance: 6 in. Loaded
- Wheels: Steel Disc, Hub Piloted, Outboard Mounted Drums
- 10 Lash Rings (5 Each Side of Deck) (HRG/SRG
- Valspar R-Cure 800 Red or Black Paint
Construction
- Four-Beam Design (HRG/SRG)
- Lights: 12 Volt DOT LED Rubber Mounted with Sealed Harness
- 1-1/2 in. Apitong Flooring Outside Mainbeams
- Options: 3rd Axle (Removable or Fixed)
General
- 12 in. Outriggers (HRG/SRG)
- Estimated Empty Weight: Starting at 14,920 lbs.
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
