Globe 40 Ton Lowboy, drawing 1399449

Globe Trailers

35-40 Ton Lowboys Standard

Photo Brochures

Capacity
40 ton
Axles
35
Deck length
29 ft
Deck height
22 in

Overview

From Globe Trailers

20" Deck Height · 20' Deck Length · 41' 11" Overall Length · 98" Swing Clearance · 54" Axle Spacing · Standard Type · 22" Deck Height · 24' Deck Length · 44' 1" Overall Length · 86" Swing Clearance · 49" Axle Spacing · Standard Type · 22" Deck Height · 24' Deck Length · 45' 11" Overall Length · 98" Swing Clearance · 54" Axle Spacing · Standard Type · 20" Deck Height · 24' Deck Length · 56' Overall Length · 86" Swing Clearance · 60" Axle Spacing · Standard Type · 22" Deck Height · 24' Deck Length · 44' 6" Overall Length · 86" Swing Clearance · 49" Axle Spacing · Standard Type · 20" Deck Height · 29' Deck Length · 55' 11" Overall Length · 102" Swing Clearance · 54" Axle Spacing · Standard Type · 20" Deck Height · 29' Deck Length · 56' 8" Overall Length · 110" Swing Clearance · 54" Axle Spacing · Standard Type · 20" Deck Height · 26' Deck Length · 46' 6" Overall Length · 102" Swing Clearance · 54" Axle Spacing · Standard Type · 22" Deck Height · 24' Deck Length · 45' 7" Overall Length · 98" Swing Clearance · 50" Axle Spacing · Standard Type · 20" Deck Height · 20' Deck Length · 41' 11" Overall Length · 98" Swing Clearance · 54" Axle Spacing · Standard Type · 20" Deck Height · 86" & 112" Swing Clearance · 54' 9" Overall Length · 29' Deck Length · 54" Axle Spacing · Hydraulic Flip Axle · 20" Deck Height · 24' Deck Length · 56' Overall Length · 86" Swing Clearance · 60" Axle Spacing · Standard Type Browse trailer specifications, photos, and features by drawing number. Looking to buy? Browse 35–40 Ton Standard Lowboy Trailers for sale in our in-stock Globe Trailers dealer inventory, or call 1-800-800-3484 for a factory-direct quote.

Specifications

Capacity

35–40 Ton Standard Lowboy Trailers for sale
in our in-stock Globe Trailers dealer inventory, or call 1-800-800-3484 for a factory-direct quote.
Rated Capacity
35-40 ton
Empty Weight
20,840 lbs

Frame

Steel Type
T-1 100K PSI yield strength steel

Safety

Safety System
Air lock safety system with safety bar

Hydraulics

Flip Axle
Patented hydraulic flip axle

Running Gear

Air Bags
30K-lb air bags standard
Axle Configuration
Tandem

Decking

Cross Member Spacing
12 inches

General

Fittings
Centralized fittings (protected from equipment contact)
Manufacturing
100% US-made, locally sourced steel, Bradenton, FL

Warranty

Structural Warranty
10-year structural warranty
Wheel Warranty
5-year STEMCO wheel warranty

Dimensions

Deck Height
22"
Deck Length Range
20' to 29'

About lowboy trailers

A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.

Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
