Kaufman Trailers
35 Ton Detachable Gooseneck Ag Trailer - 30' Well
- Capacity
- 35 ton
- Axles
- 2
- Deck length
- 30 ft
- Deck height
- 18 in
- GVWR
- 92,000 lb
Overview
From Kaufman Trailers
The 35 Ton Detachable Gooseneck Ag Trailer – 30’ Well is built to handle serious agricultural and heavy equipment hauling with strength, stability, and versatility. Rated at a 92,000 lb. G.V.W.R. with a 70,000 lb. capacity in a 12’ span or greater, this trailer features a 30’ standard well, 18” loaded deck height, and a full-depth fabricated side rail for maximum durability. Four cambered main beams constructed from 100 KSI (T1) and 80 KSI high tensile steel provide exceptional structural integrity, while the air ride suspension, 2" oak flooring, and 2 – 25,000 lb. axles ensure a smooth, dependable ride. The hydraulic, removable non-ground bearing gooseneck comes standard with wet line setup and adjustable load blocks for added flexibility. A 102” deck width expands up to 156” with slide-out aluminum outriggers, making it ideal for oversized equipment. Equipped with all-wheel air brakes, 4S/2M ABS, lifetime LED lighting, forged D-ring tie downs, and a Sherwin Williams premium acrylic urethane finish over epoxy primer, this trailer is designed for long-term performance in demanding environments.
Specifications
Capacity
- G.V.W.R.
- 92,000 lbs. (Capacity 70,000 lbs. in 12 ft. span or greater)
Dimensions
- Deck Length
- 30' well standard. Additional Optional Lengths
- Deck Height
- 18" (fully loaded)
- Deck Width
- 102" (Expandable to 156" with slide-out aluminum outriggers)
- Lower Deck
- 30' well length
- Available Lengths
- 30 ft.
Electrical
- Electrical
- Sealco US made sealed wiring harness, lifetime LED lights, amber strobe kit standard
Construction
- Frame
- Four cambered main beams, fabricated with 100 KSI (T1) and 80 KSI high tensile steel.
- Side Rail
- Full Depth Fabricated
- Floors
- 2" oak flooring
- Toolbox
- Lockable Lid Toolbox
- Ramps
- Fixed Front Ramps (See Additional Options)
- Tie Downs
- Forged D-rings
General
- Fenders
- Load bearing high tensile steel fenders over the tires.
Running Gear
- Brakes
- All wheel 16.5" x 7" air brakes, automatic slack adjusters, and 4S/2M ABS
- Wheels
- 10 hole steel disc / hub piloted (Aluminum Wheel Options)
- Tires
- 255/70 R22.5 LRH
- Axles
- 2 - 25,000 lb. axles (5" round, 5/8" wall thickness) with Flip Prep included.
- Suspension
- Air ride suspension
Gooseneck
- Tongue
- Hydraulic, removable, non-ground bearing gooseneck with 3 position adjustable load blocks and 85" - 107" available swing clearances. Comes standard set-up for wet line.
- Coupler
- SAE 2" Kingpin (16" Kingpin Setting)
Finish
- Finish
- Sherwin Williams Premium Acrylic Urethane over a Premium Two Part Epoxy Primer
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
