Kaufman Trailers
35 Ton Detachable Gooseneck Spring Ride Trailer - Dovetail Standard
- Capacity
- 35 ton
- Axles
- 2
- Deck length
- 24 ft
- Deck height
- 24 in
- GVWR
- 87,000 lb
Overview
From Kaufman Trailers
The 35 Ton Detachable Gooseneck Spring Ride Trailer – Dovetail Standard is built for dependable heavy-haul performance at an exceptional value. With an 87,000 lb. G.V.W.R. and 70,000 lb. capacity in a 12' span or greater, this model features a standard 24' well (available in 24'–28' lengths) and a 36" steel dovetail with traction cleats for efficient loading. The frame is constructed with four cambered main beams using 100 KSI (T1) and 80 KSI high tensile steel for superior strength and durability. Equipped with Hutchens H-9700 heavy-duty spring suspension, 2" oak flooring, 25,000 lb. axles, and all-wheel air brakes with ABS, this trailer is designed to handle demanding jobs with confidence. The hydraulic removable non-ground bearing gooseneck comes standard set up for wet line operation, offering 89"–107" swing clearances. Finished in Sherwin Williams premium acrylic urethane over a two-part epoxy primer, and featuring Sealco sealed wiring, lifetime LED lights, forged D-rings, and a lockable toolbox, this 35 Ton model delivers strength, reliability, and professional-grade performance.
Specifications
Capacity
- G.V.W.R.
- 87,000 lbs. (Capacity 70,000 lbs. in 12 ft. span or greater)
Dimensions
- Deck Length
- 24' well standard. Additional Optional Lengths
- Deck Height
- 24" (fully loaded)
- Deck Width
- 102" (Expandable to 126" with outriggers)
- Dovetail
- 36” Steel with Traction Cleats
- Lower Deck
- 24' well length
- Available Lengths
- 24, 26, 28 ft.
Electrical
- Electrical
- Sealco US made sealed wiring harness, lifetime LED lights, amber strobe kit standard
Construction
- Frame
- Four cambered main beams, fabricated with 100 KSI (T1) and 80 KSI high tensile steel.
- Side Rail
- Full Height Fabricated
- Floors
- 2" oak flooring
- Toolbox
- 20" x 42" Lockable Lid Toolbox
- Ramps
- Fixed Front Ramps (See Additional Options)
- Tie Downs
- Forged D-rings
General
- Fenders
- Heavy Duty Load Bearing Flat Fenders
Running Gear
- Brakes
- All wheel 16.5" x 7" air brakes, automatic slack adjusters, and 4S/2M ABS
- Wheels
- 10 hole steel disc / hub piloted (Aluminum Wheel Options)
- Tires
- 255/70 R22.5 LRH
- Axles
- 2-25,000 lb. axles (5" round, 5/8" wall thickness)
- Suspension
- Hutchens H-9700 Heavy Duty 3-Leaf Spring Suspension
Gooseneck
- Tongue
- Hydraulic, removable, non-ground bearing gooseneck with 3 position adjustable load blocks and 89" - 107" available swing clearances. Comes standard set-up for wet line.
- Coupler
- 2" oak flooring
Finish
- Finish
- Sherwin Williams Premium Acrylic Urethane over a Premium Two Part Epoxy Primer
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
