Cozad Trailers
35 Ton Flip Tail Trailer
- Capacity
- 35 ton
- Deck length
- 23 ft
- Deck height
- 23 in
Overview
The Cozad Trailers 35 Ton Flip Tail Trailer is a 35-ton RGN trailer with a 23-foot deck and a 23-inch loaded deck height. Trailers of this type typically haul tracked excavators, dozers and low-clearance machines over 30 tons.
Specifications
Construction
- Construction
- 100% A514 T-1
- Paint
- 2 Coats Primer & Paint / White STD
Dimensions
- Decking
- Douglas fir [2.5”]
- Deck / Options
- 23’ Length STD; 8’-6” Wide
- Overall Length
- 47' -11” With 8’ Gooseneck
- Deck Height (Empty)
- 27'
- Deck Height (Loaded)
- 23'
Options
- Decking
- Apitong (2.5")
- Deck / Options
- Tool Box; Auxiliary Lighting Sockets [Front & Rear Of Deck]; Outriggers (12) Heavy Duty 3" wide; 2’ Front Loading Ramps / Steel / Aluminum
- Gooseneck(s)
- 9' Mechanical Detachable; Full Screen; Spare Tire Bracket; Warn Electric Winch
- Brakes
- Air Disc (Anti-Lock)
- Tires
- Auto Air Inflation System
- Wheels
- Aluminum / 8 hole Hub Pilot
- Paint
- Your color
Gooseneck
- Gooseneck(s)
- 8' Mechanical Detachable
Running Gear
- Suspension
- Air Ride 54” Axle Spreads
- Brakes
- S Cam drum brakes
- Tires
- 235/75R x 17.5 Continental
- Wheels
- Steel Disc, 8 hole Hub Pilot
Electrical
- Lighting
- Sealco Modular Sealed Wiring System; LED Lights
Weight
- Weight (Estimated)
- 16,000 lbs.
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
