Talbert Manufacturing
35 Ton Sloping Paver
- Capacity
- 35 ton
- Axles
- 12
Specifications
Capacity
- Axles: (2) 25,000 lb. Capacity, Spacing: 55 in.
- Tires: (8) 255/70R22.5 (H) 16PR radials
Running Gear
- 16-1/2 x 7 in air actuated with 2S/1M ABS and spring brakes on 1 axle
- Wheels: 10 stud; 285.75 mm BC steel disc hub piloted system with oil seals
- RIDEWELL Suspension: Air Ride with ove ride chains on all axles
- 12 Volt LED Sealed Light System
General
- 12 in. Swinging / Removable Outriggers
- 7-pin electrical connector
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
