Globe Trailers

50-55 Ton Lowboys

Photo Brochures

Capacity
55 ton
Axles
2
Deck length
26 ft
Deck height
22 in

Overview

From Globe Trailers

Swing clearance: 102 in Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: 102 in Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Swing clearance: Not listed in the card summary; see drawing. Axles: Not listed in the card summary; see drawing. One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck. Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground. Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration. Browse trailer specifications, photos, and features by drawing number. Globe 50–55 Ton Lowboy Trailer specs at a glance: capacity 50–55 ton, deck height 18–22 in, deck length 18–30 ft, swing clearance 98–102 in, axle setup Tri-axle + flip, hydraulic detachable gooseneck (RGN) — built to order in the USA. Looking to buy? Browse 50–55 Ton Lowboy Trailers for sale in our in-stock Globe Trailers dealer inventory, or call 1-800-800-3484 for a factory-direct quote. Each Globe model number identifies a drawing and its configuration. Jump to a model card on this page for the summary specs, the drawing PDF and a quote link for that model. This range includes 50-ton models rated for 100,000 pounds, 51-ton models for 102,000 pounds, and 55-ton models for 110,000 pounds of payload. These are US short tons. Each rating applies to the specified build and the length over which the load is supported. Yes. Deck length, width, layout, and loaded height can be selected for the application. Axle options include three-axle arrangements, flip axles, lift axles, and compatible jeep or stinger setups. Standard 55-ton builds have 6 inches of loaded ground clearance: 16-inch main beams give a 22-inch deck height, 14-inch beams give 20 inches, and 12-inch beams give 18 inches. Globe manufactures its 50-55-ton lowboys in Bradenton, Florida, USA. Yes. Hydraulic detachable-gooseneck, or RGN, configurations are available in the 50-55-ton range. The neck detaches and the front of the deck lowers to the ground for front loading. Browse Globe dealer inventory for 50-55-ton lowboys, or request a factory quote online or at 1-800-800-3484 for a trailer built to your requirements. A typical Globe 50-ton hydraulic detachable-gooseneck configuration includes three axles, a non-ground-bearing neck, air-ride suspension, hardwood decking, steel front ramps, LED lighting, and a powder-coated finish. Standard equipment varies by the selected model.

Specifications

Capacity

Capacity
55 US tons
Globe 55LB1007203 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable, non-ground-bearing
Globe 50LB658939 50 Ton Lowboy
capacity 50 US tons, deck height 22 in, deck length 24 ft, gooseneck Hydraulic detachable, non-ground-bearing
Globe 55LB975302 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable, non-ground-bearing
Globe 55LB1237752 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable
Globe 55LB458712 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, gooseneck Hydraulic detachable, non-ground-bearing
Globe 55LB657073 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable, non-ground-bearing
Globe 51LB834201 51 Ton Lowboy
capacity 51 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable, non-ground-bearing
Globe 55LB546040 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, gooseneck Detachable
Globe 55LB1280363 55 Ton Lowboy
capacity 55 US tons, deck height 22 in, deck length 26 ft, gooseneck Hydraulic detachable, non-ground-bearing
50–55 Ton Lowboy Trailers for sale
in our in-stock Globe Trailers dealer inventory, or call 1-800-800-3484 for a factory-direct quote.
Rated Capacity
50-55 ton
Empty Weight
24,000 lbs

Dimensions

Deck height
22 in
Deck length
26 ft
Swing clearance
102 inAxles: Not listed in the card summary; see drawing.One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck.Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground.Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration.Download drawing PDFQuote this model
Deck Length Range
20' to 29'

Gooseneck

Gooseneck
Hydraulic detachable, non-ground-bearing

General

Standard
Paver
Paver
Beavertail
Beavertail
Most Popular
Most Popular
Globe 55LB1007203 55 Ton Lowboy55LB1007203Capacity55 US tonsDeck height22 inDeck length26 ftGooseneckHydraulic detachable, non-ground-bearingView specificationsSwing clearance: 102 inAxles: Not listed in the card summary; see drawing.One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck.Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground.Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration.Download drawing PDFQuote this model
Fittings
Centralized fittings (protected from equipment contact)
Manufacturing
100% US-made, locally sourced steel, Bradenton, FL

Running Gear

Axles
Not listed in the card summary; see drawing.One US short ton is 2,000 lb. Deck height is the distance from the ground to the deck. Swing clearance is the clearance available for the tractor to turn beneath the gooseneck.Non-ground-bearing (NGB) means the gooseneck uses the tractor fifth wheel to support the lifting action instead of a hydraulic foot against the ground.Capacity applies to the specified build and load footprint. The drawing identifies the complete configuration.Download drawing PDFQuote this model
Air Bags
30K-lb air bags standard
Axle Configuration
Tri-axle

Frame

Steel Type
T-1 100K PSI yield strength steel

Safety

Safety System
Air lock safety system with safety bar

Hydraulics

Flip Axle
Patented hydraulic flip axle

Decking

Cross Member Spacing
12 inches

Warranty

Structural Warranty
10-year structural warranty
Wheel Warranty
5-year STEMCO wheel warranty

About lowboy trailers

A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.

Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
