Talbert Manufacturing
55SA TELE
- Capacity
- 55 ton
- Deck length
- 1 ft
- Deck height
- 800 in
Specifications
Capacity
- Capacity: 110,000 lb. In a 14 ft. Two-Point Rigid Load Base (Deck Fully Retracted)
- 6 in. Loaded Road Clearance
- Capacity: 110,000 lb. In a Two-Point Rigid Load Base 4 ft. Less Than Extended Deck Length
- 1-1/2 in. Apitong Flooring tons
Gooseneck
- Hydraulic Removable Gooseneck
- Axle Capacity: 25,000 lb.
- 90 in. Swing Radius (114 in. with Gooseneck Extension)
- RIDEWELL Air Ride Suspension. 3rd and 4th Axles Can be Flipped or Removed
Hydraulics
- Hydraulically Operated Support Arm
- Talbert +3 in. / -3 in. Raising & Lowering
- Wet-Line Operation (Gas Power Pack Optional)
- Manual Control
Dimensions
- 3 ft. 0 in. Rear Deck Platform
- Tires: 275/70R22.5 (H)
- 8 ft. 6 in. Wide Deck and Rear Bridge
- 3rd Axle Can Be Used in 3+1 Spread in
- Four (4) Beam Telescopic Deck Design
- Cambered Telescopic Beams
- 20 in. Loaded Deck Height
- Valspar R-Cure 800 Top Coat Red or Black Paint
General
- 12 in. Swinging/Removable Outriggers
- Connections Rear of Axle 3
- Front Folding Ramps (Optional)
- Front Bridge Ramps
Construction
- T1/80K Construction
- Spring Parking Brake on One Axle
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
