Talbert Manufacturing

60CC/55SA-LD

Capacity
60 ton
Axles
110
Deck length
41 ft
Deck height
4 in

Overview

The Talbert Manufacturing 60CC/55SA-LD is a 60-ton RGN trailer with 110 axles, a 41-foot deck and a 4-inch loaded deck height. Trailers of this type typically haul tracked excavators, dozers and low-clearance machines over 30 tons.

Specifications

Gooseneck

Non-Ground Bearing Gooseneck Design
Manual Exhaust Valve
108 in. Swing Radius with Connections for 24 in. Gooseneck Extension
Tires: 275/70R22.5 (H)

Hydraulics

Hydraulic Support Cylinder (Standard)
Wheels: Steel Disc, Hub Piloted with Outboard Brake Drums

General

Front Folding / Fixed Ramps (Optional)
Bolsters and Half Bolster on Rear Bridge
12 in. Swinging / Removable Outriggers
Boom Well in Rear Bridge
Two Sections Chain Storage
110, 000 lb. Capacity in 10’-0” two point rigid load base with a 108” swing radius and 4 axles close coupled

Dimensions

26 ft. 0 in. Deck Length
41 in. Mainbeam / 37 in. Bolster Height
8 ft. 6 in. Wide Deck
Spring Parking Brake on Axle Two
18 in. Loaded Deck Height / 6 in. Loaded Road Clearance
4th Axle and 3+1 E1Nitro Spread Capable
1/4 in. Plate Bucket Well, Last 6 ft. of Deck
12 Volt LED Sealed Light System

Construction

High Strength 100,000 psi Minimum Yield Steel
Estimated Weight: 23,850 lbs.
2 in. Apitong Flooring
Valspar R-Cure 800 Red or Black Paint

Capacity

Axles: 25,000 lb. Capacity
110,000 lb. Capacity in 1/2 Deck Length two point rigid load base with a 132” swing radius and 3+1 E1 nitro axles extension

Running Gear

RIDEWELL Suspension: Air Ride with Automatic and Talbert +3 in. / -3 in. Manual Control
120,000 lb. Capacity in 1/2 Deck Length two point rigid load base with a 108” swing radius and 4 axles close coupled

About removable gooseneck trailers

A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.

Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
