Talbert Manufacturing

60SA

Capacity
60 ton
Axles
22
Deck height
41 in

Overview

The Talbert Manufacturing 60SA is a 60-ton RGN trailer with 22 axles and a 41-inch loaded deck height. Trailers of this type typically haul tracked excavators, dozers and low-clearance machines over 30 tons.

Specifications

Gooseneck

Non-Ground Bearing Gooseneck Design
RIDEWELL Suspension: Air Ride with Automatic and Talbert +3 in. / -3 in. Manual Control

Dimensions

108 in. Swing Radius (Other Lengths Optional)
Manual Exhaust Valve
25 ft. 0 in. Deck Length
Bolsters and Half Bolster on Rear Bridge
22 in. Loaded Deck Height
41 in. Mainbeam / 37 in. Bolster Height
6 in. Loaded Road Clearance
Bucket Well in Rear Bridge
8 ft.-6 in. Deck Width
4th Axle and 3+1 Spread Capable
1/4 in. Plate Bucket Well in Last 6 ft. of Deck
12 Volt LED Sealed Light System

Hydraulics

Hydraulic Support Cylinder (Standard)
Tires: 275/70R22.5 (H)

General

Front Folding / Fixed Ramps (Optional)
Wheels: Steel Disc, Hub Piloted with Outboard Brake Drums
12 in. Swinging / Removable Outriggers
Spring Parking Brake on Axle Two

Construction

High Strength 100,000 psi Minimum Yield Steel
Valspar R-Cure 800 Red or Black Paint
2 in. Apitong Flooring
Capacity: 120,000 lb. in ½ Deck Length

Capacity

Axles: 25,000 lb. Capacity
Estimated Weight: 22,590 lbs.

About removable gooseneck trailers

A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.

Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
