Cozad Trailers
70/75 Ton California Baby 9-Axle Trailer
- Capacity
- 75 ton
- Axles
- 9
- Deck length
- 26 ft
- Deck height
- 18 in
Overview
The Cozad Trailers 70/75 Ton California Baby 9-Axle Trailer is a 70–75-ton RGN trailer with 9 axles, a 26-foot deck and a 18-inch loaded deck height. Trailers of this type typically haul tracked excavators, dozers and low-clearance machines over 30 tons.
Specifications
Construction
- Construction
- 100% HT 130 Steel
- Paint
- 2 coats primer & paint; White STD / Your color
- Outriggers
- (18) Heavy Duty 3" wide
Dimensions
- Decking
- Douglas fir (3") / Apitong
- Deck Length
- 26' STD / 28 -30' optional
- Flat Deck Height
- 21" - 23" loaded - estimates only
- Drop Side Height
- 16" - 18" loaded - estimates only
- Deck Width
- 8'6" STD
- Overall Length
- 86'
Gooseneck
- Gooseneck(s)
- Mechanical Detachable
Running Gear
- Suspension
- Walking Beam and Air
- Axles
- IMT 25,000 lb w/ oil seals
- Brakes
- Drum S-cam / DISC Brakes
- Tires
- 265/70R x 19.5 Continental
- Wheels
- Steel Disc, 10 hole / Aluminum
Hydraulics
- Hydraulic Lift
- Kholer 25 hp Electric pull-start; Gas engine w/2 50 ton hydraulic Rams; 24" lift
Electrical
- Lighting
- Grote Modular Sealed; Wiring System LED
Weight
- Estimated Weight
- 37,500 lbs +/-
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
