Landoll Trailers

825-AG Detachable Trailer

Features

Capacity
28 ton
Axles
2
Deck height
17 in

Overview

From Landoll Trailers

800 Series Ag Detachable Trailers are designed with an innovative four-beam frame and gooseneck give the operator versatility required to safely load and legally transport today’s heavy, wide and tall equipment. The 800 frame design features a flat deck with a loaded height of 17” off the ground. Coupled with a low tare weight, the 825 can haul the latest combines, tillage, haying equipment and planters with up to 32′ of usable deck space. A single hydraulic control lever lowers, detaches and activates the patented gooseneck carrier arms, which allows the ease and simplicity of detaching and loading directly onto the lower deck which is only 11¼” off the ground. You will never have to drive up and over the trunnion again. * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. Specifications subject to change without notice. Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment. The information on any form of this website is intended only for the sole use of Landoll. We do not share or sell any of this information to third parties. This drawing and all information therein is property of Landoll and is confidential. It must not be made public or copied. This drawing is loaned subject to return upon demand and shall not be used directly or indirectly in anyway detrimental to our interest. Drawing illustrates standard equipment; optional equipment may change standard measurements. 800-428-5655 moc.llodnal@selasreliart

Specifications

Capacity

Capacity*
27.5 Ton (55,000 lbs.)
Estimated Base Weight
16,400 lbs. (49′) 16,950 lbs. (51′)

Dimensions

Deck Rating
50,000 lbs. in 16′
Deck Width
102″
Loaded Deck Height
17″
Loaded Ground Clearance
7″
Decking
1-1/2″ Apitong, Full Width
Swing Clearance
84″
Lower Deck Tie Downs
Double Keyhole Chain Slots Located on 36″ Centers; Side Mounted Nylon Strap / Chain Tie Downs

Frame

Main Frame
Fabricated 10″, 100,000 PSI Flange
Wet Kit for Tractor (Includes 30 Gallon Steel Tank)
Shipped loose with trailer or factory installed

General

Crossmembers
5″ x 3″ High Tensile Tubing on 18″ Centers
Pin Setting
15″
Side Extension
27″ Aluminum Telescoping Extensions (Lower Deck) (Capacity-7,000 lbs. EACH Extension)
Tool Box
No Standard Tool Box
Rear Trunnion Tie Downs
D-Rings: 2 Each at Base Flush Mounted on Top of Inner Beams; 2 Each at Rear Flush Mounted on Top of Inner Beams; 2 Each at Top of Slope on Outer Web
Grease
Centralized Grease System
Rims
22.5 x 8.25
Oil Seal Hubs
Internal Mated Assembly
Air
Glad Hand
Powder Coat Color
White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue
Decals
Hi-Visibility Reflective Package
Delete 27″ Aluminum Telescoping Side Extensions
28′ Deck
Model
Capacity*
825-49
27.5 Ton
825-51
27.5 Ton
Certifications
Cage Code — 65459; Small Business NAICS Codes — 336211, 336413, 333111, 333924, 336212 Copyright © 2026 Landoll Company, LLC. All Rights Reserved.

Gooseneck

Hitch
Automatic Gooseneck Lock Engagement
Gooseneck
12′
Gooseneck Tie Downs
D-Rings: 2 Each Front Corner; 2 Each Back

Running Gear

Suspension
SAF Air Ride 25,000 lbs. Capacity
Axles
(2 ) 25,000 lbs. Tandem Dual Tire, Oil Bath Bearings
Brakes
16.5 x 7 Full Air / Spring Brakes Both Axles, ABS 4S2M, Automatic Slack Adjusters
Tires
255/70R 22.5 LRH Continental
Wheels
Steel Hub Pilot

Hydraulics

Hydraulic Hook Up
Quick Couplers 2,500 PSI – 20 GPM at Controls, 50GPM Max
Cylinders
Gooseneck Cylinders Horizontally Mounted

Electrical

Electrical
7-Way Receptacle
Lights
Industry Best Grote LED Lighting with Oven Annealed Markers (Up to a 10-year warranty)
Wiring Harness
Industry Best Grote Xtreme Harnessing (7-year warranty)
Four Corner Light Package
Consult factory

Finish

Finish
Steel Grit Shot Blast to Bright Metal
Paint Over Galvanizing
Sides only of Lower Deck and Trunnion Slope with Standard Colors only

About lowboy trailers

A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
