Landoll Trailers

835-AG Detachable Trailer

Features

Capacity
35 ton
Axles
2
Deck height
18 in

Overview

From Landoll Trailers

The 835F-AG Detachable Trailers are designed with an innovative four-beam frame and gooseneck which give the operator versatility required to safely load and legally transport today’s heavy, wide and tall equipment. The 835F-AG can be a rigid 3-axle or be equipped with an optional flip third axle. The 835F-AG frame design features a flat deck with a loaded height of 18-1/4” off the ground. Coupled with a low tare weight, the 835F-AG can haul the latest combines, tillage, haying equipment and planters with up to 32′ of usable deck space. A single hydraulic control lever lowers, detaches and activates the patented gooseneck carrier arms, which allows the ease and simplicity of detaching and loading directly onto the lower deck which is only 11¼” off the ground. You will never have to drive up and over the trunnion again. * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. 102” wide (with Weight Cut Out Package) 120” wide (with Weight Cut Out Package) * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. Specifications subject to change without notice. Disclaimer: below shows optional 3rd flip axle Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment. The information on any form of this website is intended only for the sole use of Landoll. We do not share or sell any of this information to third parties. This drawing and all information therein is property of Landoll and is confidential. It must not be made public or copied. This drawing is loaned subject to return upon demand and shall not be used directly or indirectly in anyway detrimental to our interest. Drawing illustrates standard equipment; optional equipment may change standard measurements. 800-428-5655 moc.llodnal@selasreliart

Specifications

Capacity

Capacity*
35 Ton (70,000 lbs.)
Estimated Base Weight
18,000 lbs., (835F-AG) +/- 3%

Dimensions

Deck Rating
60,000 lbs. in 12′
Deck Width
102″
Loaded Deck Height
18-1/4″
Loaded Ground Clearance
7″
Decking
1-1/2″ Apitong, Full Width
Swing Clearance
84″
Lower Deck Tie Downs
Side Mounted Nylon Strap / Chain Tie Downs; Side Mounted D-Rings on 36″ Centers
Removable Aluminum Upper Deck
Full Width for 12′ Gooseneck (124″L x 102″ W) 14,000 lbs. Capacity
Adjustable Aluminum Ladder Ramp with Rod Bracket, Full Width uses ONE of the Following
102” wide 120” wide 102” wide (with Weight Cut Out Package) 120” wide (with Weight Cut Out Package)

Frame

Main Frame
Fabricated 11 1/4″ Beam, 100,000 PSI Yield Flanges
Wet Kit for Tractor (Includes 30 Gallon Steel Tank)
Shipped loose with trailer or factory installed

General

Crossmembers
5″ x 3″ Rec. Tube on 18″ Centers
Pin Setting
15″
Side Extension
27″ Aluminum Telescoping Side Extensions (Lower Deck)
Accessories
835F-AG – 48′, 51′ or 53′ Frame Prepared with Bkts, Electric and Air for 3rd Axle Flip
Tool Box
None Standard
Rear Trunnion Tie Downs
D-Rings: (2) Each at Base Flush Mounted on Top of Inner Beams; (2) Each Web Mounted on Top; (2) Each Rear Flush Mounted on Top of Inner Beams; (2) Each Top of Slope (Outer web)
Grease
Centralized Grease System
Rims
22.5 x 8.25 Steel
Oil Seal Hubs
Internal Mated Assembly
Powder Coat Color
White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue
Decals
Hi-Visibility Reflective Package
Model
Capacity*
835-48Ag
35 Ton
835-51Ag
35 Ton
835-53Ag
35 Ton
835-R-53AG-S50
35 Ton
835-R-53AG-S60
35 Ton
Certifications
Cage Code — 65459; Small Business NAICS Codes — 336211, 336413, 333111, 333924, 336212 Copyright © 2026 Landoll Company, LLC. All Rights Reserved.

Gooseneck

Hitch
Patented Automatic Gooseneck Lock Engagement
Gooseneck
11′ 9″
Gooseneck Tie Downs
D-Rings: (2) Each at Front Corner; (2) Each at Back

Running Gear

Suspension
SAF Air Ride, 25,000 lbs. Capacity
Axles
(2) 25,000 lbs. Axles, Dual Tire, Oil Bath Bearings, Automatic Slack Adjusters
Brakes
16.5 x 7 Full Air / Spring Brakes, ABS 4S2M
Tires
255/70R 22.5 LRH Continental
Wheels
Steel Hub Pilot

Hydraulics

Hydraulic Hook Up
Quick Couplers / 2,500 PSI – 20 GPM at Controls; 50GPM Max
Cylinders
Gooseneck Cylinder Hoizontally Mounted
Hydraulic Engine Package
Gooseneck Mounted with Cover 25HP EFI Kohler Gas Includes Mounting Kit

Electrical

Air / Electrical
7-Way Receptacle
Lights
Industry Best Grote LED Lighting with Oven Annealed Markers (Up to a 10-year warranty)
Wiring Harness
Industry Best Grote Xtreme Harnessing (7-year warranty)
Four Corner Light Package
Consult factory

Finish

Finish
Steel Grit Shot Blast to Bright Metal
Paint Over Galvanizing
Sides only of Lower Deck and Trunnion Slope with Standard Colors only

About lowboy trailers

A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.

Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
