Landoll Trailers
930 Traveling Tail Trailer
Features
- Capacity
- 35 ton
- Axles
- 2
- Deck height
- 38 in
Overview
From Landoll Trailers
The 930 Traveling Tail is part of the 900 Series trailers. The tail is capable of lifting 24,000 lbs up to 53″ dock height. Maximize your loads by utilizing the entire deck and maximize your payload by having the undercarriage five feet behind the main hinge. The longer wheelbase gives you proper weight distribution between tractor and trailer and fully supports the tail. The traveling tail concept allows for stable dock loading and increases your payload by having a longer wheelbase. Quick, simple, safe operation and a longer wheelbase that increases payload. A 15′ tail reduces the load angle to a low 11°. Frames are steel shot blasted in preparation for the TGIC polyester powder coat paint finish standard on 900 E-Series trailers. The tail can raise and lift 24,000 lbs up to 57″ dock height. The 900 Series trailers are backed by a 5-year structural warranty. The low-load tail angle ensures easy clearance for loading low-sitting equipment, providing seamless loading capabilities. The hydraulic control allows for efficient and convenient loading and unloading operations, all managed through a single control point. Apitong Wood Covered Tail Gotchas on 16″ Centers (6) Double Keyhole Chain Slots on Tail (2) D-Rings Lower Slope at Deck Center Deck Keyholes on Tail * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. Automatic Slack Adjusters Side Opening Toolboxes Lower Deck Bolt-On Lockable Toolbox Lower Deck Turn/Flashing Lights 245/70R 17.5 Michelin X Multi T LRH 255/70R 22.5 Double Coin 255/70R 22.5 Michelin (Standard Colors Only) * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations. Specifications subject to change without notice. Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment. The information on any form of this website is intended only for the sole use of Landoll. We do not share or sell any of this information to third parties. This drawing and all information therein is property of Landoll and is confidential. It must not be made public or copied. This drawing is loaned subject to return upon demand and shall not be used directly or indirectly in anyway detrimental to our interest. Drawing illustrates standard equipment; optional equipment may change standard measurements. 800-428-5655 moc.llodnal@selasreliart
Specifications
Capacity
- Capacity*
- 35 Ton (70,000 lbs.)
- Estimated Base Weight
- 16,300 lbs. (48′) +/-3%
- Tail Lifting Capacity
- 24,000 lbs.
Dimensions
- Deck Rating
- 50,000 lbs. in 10′
- Swing Clearance
- 84″
- Deck Width
- 102″
- Loaded Deck Height
- 38″
- Loaded Ground Clearance
- 20″
- Decking
- 1-3/8″ Nominal Apitong Wood (Lower Deck) Apitong Wood Covered Tail
- Swing-Out Lights
- Upper Deck Turn/Flashing Lights Lower Deck Turn/Flashing Lights
Frame
- Main Frame
- Fabricated 80,000 PSI Yield 4-Beam Design
- Wet Kit for Tractor (Includes 30 Gallon Steel Tank)
- Shipped loose with trailer or factory installed
General
- Crossmembers
- 4″ Junior I-Beam and 3″ Junior I-Beam on 8″ Centers
- Slope Drop
- 90°
- Parking Stands
- Jost Two Speed Landing Gear
- Pin Setting
- 18″
- Tool Box
- Twin Upper Deck Mounted Top-Opening with Non-Weight Bearing Illuminated Lids
- Tie Downs
- Double Keyhole Chain Slot Gotchas on 16″ Centers (6) Double Keyhole Chain Slots on Tail (2) D-Rings Lower Slope at Deck Center Deck Keyholes on Tail
- Features
- Flat Approach Plate
- Undercarriage
- Centralized Grease System
- Rims
- 17.5 x 6.75 Tubeless
- Oil Seal Hubs
- Internal Mated Assembly
- Primer
- Zinc Rich Primer
- Powder Coat Color
- White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue
- Decals
- Hi-Visibility Reflective Package
- Bulkhead
- 16″/24″ 2 Position 48″ x 102″ Mesh
- Bulkhead Wings
- Steel Wings (Powder Coat Black) Aluminum Wings
- D-Rings
- Flush Mounted Bolt-On at Winch Recessed Mounted
- Cable Roller Guide
- 4-Way Rollers Pivoting
- Toolboxes
- Load Bearing, Self-Supporting, Top Opening Toolboxes Side Opening Toolboxes Lower Deck Bolt-On Lockable Toolbox
- Traction Bars for Tail
- Weld On 12′ Tail Weld On 15′ Tail
- Model
- Capacity*
- 930E-45-12
- 35 Ton
- 930E-48-12
- 35 Ton
- 930E-48-15
- 35 Ton
- 930E-51-15
- 35 Ton
- Note
- All Bulkhead options require the 48″ X 102″ Bulkhead Bulkhead Wings Steel Wings (Powder Coat Black) Aluminum Wings Aluminum LED Light Bar (Stop, Turn, and Taillights) with Chain Binder Rack Dual LED Work Lights Dual Class II Strobe Beacons Bolt-On Chain-Binder Rack Spare Tire Carrier Parking Stands Pin Drop Tie Downs D-Rings Flush Mounted Bolt-On at Winch Recessed Mounted Winch & Accessories Winch 20K Winch (Braden) 12K Delete Standard Winch 20k or 30K Winch (Warn) Winch Guard Cable Roller Guide 4-Way Rollers Pivoting Wireless Remote Control Six Function Deck & Accessories Toolboxes Load Bearing, Self-Supporting, Top Opening Toolboxes Side Opening Toolboxes Lower Deck Bolt-On Lockable Toolbox Traction Bars for Tail Weld On 12′ Tail Weld On 15′ Tail Bolt-On Landoll Traction Plate over Approach Keyhole Tie Downs for Center Main Deck Double Drop Deck Swing-Out Lights Upper Deck Turn/Flashing Lights Lower Deck Turn/Flashing Lights Suspension & Undercarriage Digital Scale System Galvanized Bumper Hydraulic Power Source Wet Kit for Tractor (Includes 30 Gallon Steel Tank) Shipped loose with trailer or factory installed Hydraulic Quick Coupler Kit (1 male, 1 female) Polished Aluminum Hydraulic Tank, (19″W x 24D”) (Side mount) Kohler EFI, 25 HP, Gas Powered Hydraulic Engine Package with Cover Upper Deck Mounted Under Deck Mounted Tires & Rims 17.5 Machined Aluminum Wheel (Priced per tire) 17.5 Polished Aluminum Wheel (Priced per tire) 22.5 Machined Aluminum Wheel (Priced per tire) 22.5 Polished Aluminum Wheel (Priced per tire) Tires 235/75R 17.5 Double Coin 245/70R 17.5 Michelin X Multi T LRH 255/70R 22.5 Double Coin 255/70R 22.5 Michelin Spare Tires Available with Rim of Choice PSI Tire Inflation System Hubometer Paint & Special Hot Dip Galvanizing Paint Over Galvanizing Sides Top Surface (Standard Colors Only) Wet Paint Colors Black (Standard), Metallic Gray, White, Red, Viper Red, Green, Balboa Blue, Sapphire Blue, Yellow Powder Coat Paint only available with Non-Galvanized Trailers Powder Coat Paint Colors Black (Standard), Metallic Gray, White, Red, Viper Red, Green, Balboa Blue, Sapphire Blue, Yellow Special Paint: Contact Factory Specifications Model Capacity* Base Weight Length Tail Length Deck Axles Tires & Ply Ratings 930E-45-12 35 Ton 17,265 lbs. (+/- 3%) 45′ 12′ 102″ x 35’ 3″ 2 (8) 235/75R 17.5 LRJ Double Coin 930E-48-12 35 Ton 17,660 lbs. (+/- 3%) 48′ 12′ 102″ x 38’ 3″ 2 (8) 235/75R 17.5 LRJ Double Coin 930E-48-15 35 Ton 18,770 lbs. (+/- 3%) 48′ 15′ 102″ x 38’ 3″ 2 (8) 235/75R 17.5 LRJ Double Coin 930E-51-15 35 Ton 19,250 lbs. (+/- 3%) 51′ 15′ 102″ x 41’ 3″ 2 (8) 235/75R 17.5 LRJ Double Coin * Capacity ratings are frame capacities only. Actual load capacities may be restricted by factors such as gross axle weight ratings (GAWR) or state and federal regulations.Specifications subject to change without notice.Disclaimer: Landoll has a corporate policy of continuous product improvement and development, therefore, specifications are subject to change without any advance notice. Landoll is not responsible for differences between the specifications or illustrations contained on literature, data sheets, website and actual equipment. The information on any form of this website is intended only for the sole use of Landoll. We do not share or sell any of this information to third parties. This drawing and all information therein is property of Landoll and is confidential. It must not be made public or copied. This drawing is loaned subject to return upon demand and shall not be used directly or indirectly in anyway detrimental to our interest. Drawing illustrates standard equipment; optional equipment may change standard measurements.Line Drawing (PDF)GalleryPress O for more optionsClick for sound
- Certifications
- Cage Code — 65459; Small Business NAICS Codes — 336211, 336413, 333111, 333924, 336212 Copyright © 2026 Landoll Company, LLC. All Rights Reserved.
Gooseneck
- Hitch
- Fifth-Wheel Kingpin
Loading
- Load Angle
- 11° with 15′ Tail
Running Gear
- Suspension
- SAF Air Ride RLU228, 22,500 lbs. Capacity with Manual Dump Valve
- Axles
- (2) 25,000 lbs. Dual Tire Axles, Oil Bath Bearings Outboard Brake Drum Automatic Slack Adjusters
- Brakes
- 12.25 x 7.5 Full Air / Spring Brakes ABS 4S2M
- Tires
- 235/75R 17.5 LRJ Continental
- Wheels
- Steel Hub Pilot
Hydraulics
- Hydraulic Hook Up
- Quick Couplers / 2,500 PSI – 20 GPM at Controls, 50 GPM Max
- Hydraulic Winch
- Upper Deck 12,000 lbs. Worm Gear 85′ of 1/2″ Cable Wear Plate
- Hydraulic Valve Body
- Rexroth
- Winch
- 20K Winch (Braden) 12K Delete Standard Winch 20k or 30K Winch (Warn)
- Kohler EFI, 25 HP, Gas Powered Hydraulic Engine Package with Cover
- Upper Deck Mounted Under Deck Mounted
Electrical
- Air / Electrical
- 7 Way Receptacle
- Lights
- Industry Best Grote LED Lighting with Oven Annealed Markers (Up to a 10-year warranty)
- Wiring Harness
- Industry Best Grote Xtreme Harnessing (7-year warranty)
Finish
- Finish
- Steel Grit Shot Blast to Bright Metal
- Paint Over Galvanizing
- Sides Top Surface (Standard Colors Only)
- Wet Paint Colors
- Black (Standard), Metallic Gray, White, Red, Viper Red, Green, Balboa Blue, Sapphire Blue, Yellow
- Powder Coat Paint Colors
- Black (Standard), Metallic Gray, White, Red, Viper Red, Green, Balboa Blue, Sapphire Blue, Yellow
Controls
- Wireless Remote Control
- Six Function
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
