Trail King
HD-S
Find Your Specialized Solution
- Capacity
- 55 ton
- Deck height
- 14 in
Overview
TKHD-S Designed for serious heavy-duty hauling, Trail King’s new HD-S trailer delivers unmatched strength, capacity, and control. Built to handle up to 110,000 lb., this trailer features a double box beam-style deck with option to be extendable that maximizes versatility for a wide range of load types. Call our toll-free number 800-843-3324 The literature and image assets in this tab are digital assets, best for viewing online. To request print literature or media, please contact your District Sales Manager. Operation Manual HD-S Service & Maintenance Manual HD-S Trail King Paint Options Trail King – HD-S in Augmented Reality powered by JigSpace
Specifications
Frame
- Perimeter Expanding Frame – Standard Equipment
- TK160
Capacity
- Capacity
- 110,000 lbs. overall, reinforced for single pin on axle (optional reinforced for single axle booster), 90,000 lbs. in 10’ closed lbs
Dimensions
- Swing clearance
- 125”
- Loaded deck height
- 14” with 4” ground clearance
Gooseneck
- Automatic kingpin steering system
- 35° steering angle
General
- Manual override steering
- 40° of steering angle
About double drop trailers
A double drop has two steps: one behind the neck and one ahead of the rear axles, forming a low well in the middle. The well sits close to the ground and typically runs 25 to 29 feet, which is where tall, heavy items ride — presses, transformers, compact cranes. Detachable and fixed-neck versions exist, and extendable wells handle over-length pieces.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
