Fontaine Trailer
Magnitude 55H MFLD
- Capacity
- 55 ton
- Axles
- 3
- Deck length
- 26 ft
- Deck height
- 22 in
Overview
The Fontaine Trailer Magnitude 55H MFLD is a 55-ton lowboy trailer with 3 axles, a 26-foot deck and a 22-inch loaded deck height. Trailers of this type typically haul excavators, dozers, cranes and drill rigs.
Specifications
Capacity
- Standard SpecificationsCapacity 55 tons in 12-foot length with 4 axle close coupled or single axle stinger - GAWR and GVWR determine legal payloadsTrailerLength
- Width:GooseneckDesign:Hydraulic removable non-ground bearing designSwing radius:102 inches (11 feet 11 inches overall gooseneck length)DeckDeck type:MFLDDeck length:Deck width:8' 6" or 9"Loaded deck height/clearance:22 inches with 6 inches ground clearanceFlooring:2 inch nominal apitong - side rails onlyAxlesStandard trailer axles:3Axle Capacity:25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other componentsAxle spread:54.5" or 60"BogieDeck to bogie connection:ModularRear bogie height:41 inchesDesign:Covered Rear Bogie:TiresTire size:275/70R 22.5 OEM Standard
- Capacity 55 tons in 12-foot length with 4 axle close coupled or single axle stinger - GAWR and GVWR determine legal payloadsTrailerLength
- Width:GooseneckDesign:Hydraulic removable non-ground bearing designSwing radius:102 inches (11 feet 11 inches overall gooseneck length)DeckDeck type:MFLDDeck length:Deck width:8' 6" or 9"Loaded deck height/clearance:22 inches with 6 inches ground clearanceFlooring:2 inch nominal apitong - side rails onlyAxlesStandard trailer axles:3Axle Capacity:25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other componentsAxle spread:54.5" or 60"BogieDeck to bogie connection:ModularRear bogie height:41 inchesDesign:Covered Rear Bogie:TiresTire size:275/70R 22.5 OEM Standard
- Axle Capacity
- 25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other components
- 25,000 lb. nominal capacity per axle NOTE
- GAWR determined by suspension type, brakes, tires and other components
General
- TrailerLength
- Width:
- Design
- Hydraulic removable non-ground bearing design
- Swing radius
- 102 inches (11 feet 11 inches overall gooseneck length)
- DeckDeck type
- MFLDDeck length:Deck width:8' 6" or 9"Loaded deck height/clearance:22 inches with 6 inches ground clearanceFlooring:2 inch nominal apitong - side rails only
- Deck type
- MFLD
- Flooring
- 2 inch nominal apitong - side rails only
- BogieDeck to bogie connection
- ModularRear bogie height:41 inchesDesign:Covered Rear Bogie:
- Deck to bogie connection
- Modular
- Rear bogie height
- 41 inches
Gooseneck
- GooseneckDesign
- Hydraulic removable non-ground bearing designSwing radius:102 inches (11 feet 11 inches overall gooseneck length)
Dimensions
- Deck width
- 8' 6" or 9"
- Loaded deck height/clearance
- 22 inches with 6 inches ground clearance
Axles
- AxlesStandard trailer axles
- 3Axle Capacity:25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other componentsAxle spread:54.5" or 60"
- Standard trailer axles
- 3
- Axle spread
- 54.5" or 60"
Tires & Wheels
- TiresTire size
- 275/70R 22.5 OEM Standard
- Tire size
- 275/70R 22.5 OEM Standard
About lowboy trailers
A lowboy drops the deck between the gooseneck and the rear axles, putting the load 18 to 24 inches off the ground. That low center of gravity is what lets tall equipment — excavators, dozers, cranes, drill rigs — travel under bridges without an over-height permit. Fixed-neck lowboys load from the rear or side; detachable-neck models let the machine drive straight on from the front. Typical capacities run 35 to 60 tons, with multi-axle configurations reaching well beyond that.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
