Trail King
Paver Special
Interested in Our Hauling Solutions?
- Capacity
- 46 ton
- Axles
- 55
- Deck length
- 24 ft
Overview
Five-Position Gooseneck Door Adjustment 42 inch Front Ramps with Spring Assist and an 11° Load Angle 4-Beam Tapered Deck Main Frame Construction 18° Rear Slope with Knife Edge Transition to the Deck This Hydraulic Detachable Gooseneck Paver Special trailer is dependable, strong, durable, and versatile. We’ve taken our bestselling detachable lowboy and integrated its top features into this piece of equipment. Its easy-load angles and low profile create a hassle-free loading experience for construction equipment, including asphalt pavers and rollers. Call our toll-free number 800-843-3324 The literature and image assets in this tab are digital assets, best for viewing online. To request print literature or media, please contact your District Sales Manager. Trail King Paver Special Protect Your Investment with Our Complete Line of Services Trail King Paint Options We don’t have any current videos of this product on our YouTube channel (YET), but go subscribe so you don’t miss any new uploads!
Specifications
General
- PAVER SPECIAL STANDARD EQUIPMENT
- TK102HDG
- 42″ front ramps w/spring assist
- X
Capacity
- Concentrated capacity (in 16′)
- 92,000 lbs lbs
Gooseneck
- Gooseneck
- 11’11”
- 5-position gooseneck heigh adjustment +/- 3″
- X
Dimensions
- Swing Clearance
- 98″ & 86″
- 4-beam tapered deck main frame construction
- X
- 22″ loaded deck height, 6″ ground clearance
- X
- Deck Width
- 102”
- Deck Length
- 24’1”
- 18° Rear Slope with Knife Edge Transition to the Deck
- Paver SpecialThis Hydraulic Detachable Gooseneck Paver Special trailer is dependable, strong, durable, and versatile. We’ve taken our bestselling detachable lowboy and integrated its top features into this piece of equipment. Its easy-load angles and low profile create a hassle-free loading experience for construction equipment, including asphalt pavers and rollers.
Running Gear
- Wood-covered wheel area w/18* slope
- X
- Axle Spacing
- 55”
About removable gooseneck trailers
A removable gooseneck trailer is a lowboy whose front neck detaches — hydraulically or mechanically — so the deck rests on the ground and becomes its own ramp. Tracked and low-clearance machines drive on from the front without separate ramps or a dock. RGNs are the default choice for excavators over 30 tons, and the format scales with added axles, jeeps and boosters into the 100-ton-plus range for permitted loads.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
