XL Specialized Trailers
XL Step Deck Extendable
Detachable Gooseneck
- Capacity
- 40 ton
- Axles
- 2
- Deck length
- 62.3 ft
- Deck height
- 40 in
Overview
The XL Step Deck Extendable is a 40-ton step deck trailer with 2 axles, a 62.3-foot deck and a 40-inch loaded deck height. Trailers of this type typically haul freight up to about 10 feet tall, wheeled equipment and machinery.
Specifications
Capacity
- OverallCapacity
- 80,000 lbs
- ConcentratedCapacity
- 60,000 lbs in 10' closed
Dimensions
- Gooseneck Length
- 10'
- Main DeckLength Range
- 38' - 62' 4"
- Loaded Deck Height
- 40"
Running Gear
- Standard Axles
- 2
- Wheel Area
- Covered wheels
General
- Standard OAL
- 48'
- ISO 9001
- 2015 Registered
About step deck trailers
A step deck (or drop deck) has a short upper deck over the fifth wheel and a longer lower deck stepped down behind it. The lower deck sits around 36 to 40 inches high — roughly two feet lower than a flatbed — so it carries freight up to about 10 feet tall without an over-height permit. Common lengths are 48 and 53 feet, with ramps optional for wheeled equipment.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
